Supplemental alarm for 2018 Raptor

Discussion in 'Audio/Video/Electronics' started by Bruce CREG, May 14, 2018.

  1. Bruce CREG

    Bruce CREG Member

    Posts:
    9
    Likes Received:
    0
    Joined:
    Mar 15, 2018
    Location:
    Los Angeles, California
    I took delivery of my 2018 Raptor with the keyless security entry system and 802A accessory package plus others, but I don't believe they matter concerning improving the current alarm system.

    I'd like to hear recommendations on exceptional quality alarm accessories or systems and my budget would be a less than a thousand.

  2. rob7765

    rob7765 Member

    Posts:
    5
    Likes Received:
    3
    Joined:
    Mar 11, 2016
    This is a cheap add on that adds a little more protection with shock/impact.


    https://accessories.ford.com/electronic-module-10670.html


    I sell this bracket to mount it instead of zip ties like the instructions show.


    https://bajamod.com/detail.php?product_code=BM1016&color=


    Also don’t forget about the Ford Pass app for your phone that alerts you to alarm trigger and also lets you arm, lock, unlock, remote start, gps track, etc






    Vikes91 likes this.
  3. Adam

    Adam Full Access Member

    Age:
    44
    Posts:
    178
    Likes Received:
    31
    Joined:
    Aug 31, 2017
    Location:
    New Orleans La
  4. stratia69

    stratia69 Member Military

    Posts:
    7
    Likes Received:
    4
    Joined:
    Jan 23, 2018
    Location:
    Lacey, WA
    Can anyone confirm that that module differs from what is already installed on 2018"s? It already has perimeter security that can be adjusted to High/Low through the console. I thought this was an upgrade for previous model that did not have it. Just trying to conform.

  5. Bruce CREG

    Bruce CREG Member

    Posts:
    9
    Likes Received:
    0
    Joined:
    Mar 15, 2018
    Location:
    Los Angeles, California
    Thank you for the referral. In checking that part number and your link, it seems it fits the F150 for years 2011-2014 (aka part # DL3Z-19A361-A). This may be the correct part for 2017 & 2018 Raptors, see https://www.levittownfordparts.com/...curity-system-ford-perimeter-plus-p-6139.html for further details. As too stratia69's question, I'm going to check my 2018 Ford Raptor to see if it has the high/low adjustment. I purchased mine with the 802A package along with other accessories.

  6. Bruce CREG

    Bruce CREG Member

    Posts:
    9
    Likes Received:
    0
    Joined:
    Mar 15, 2018
    Location:
    Los Angeles, California
    Just ordered my Ford OEM Ford Security System sensor from Fairway Ford (Nate in parts) who was very helpful. Price to CA was $184.95, includes free shipping and they include installation instructions. Link here - https://www.fairwayfordparts.net/oe...g-explorer-super-duty-continental-js7z19a361a

    If your Raptor already has remote start capabilities, then you should be able to install this without taking it to the dealership or so I've read and been told by Nate in parts.

  7. Bruce CREG

    Bruce CREG Member

    Posts:
    9
    Likes Received:
    0
    Joined:
    Mar 15, 2018
    Location:
    Los Angeles, California
    My 2018 Raptor includes but is not limited to the 802A accessory package and has remote start, so the part I ordered from Fairway Ford is super easy to install. Install the wiring Y harness into the back of the module with the Data Link Connector (DLC) which is right under the dash on the drivers side. If you're car has remote start you don't need the extra plug that comes with the sensor. I have no idea how you are supposed to install the VSS Module with the included zip ties, none of the holes lined up. When testing the unit per the instructions, wait 20 or 30 seconds after setting the alarm for the first time before hitting the steering wheel to check sensitivity, but mine worked fine with the VSS unit hanging down for the test. I'm going to get some wide velcro and use that to mount the VSS module, however the instructions say "Ensure the tie-strap is routed through the VSS module loopos at opposite corners." If someone has mounted their VSS unit with zip ties, please post. As soon as I install the VSS module with Velcro I'll post pictures.

  8. df105

    df105 Member

    Posts:
    10
    Likes Received:
    2
    Joined:
    Sep 30, 2018
    I couldn't get a straight answer out of my Ford dealer parts guy that the perimeter plus is or is not included in the 2018 Raptor with 802A package. He seemed to be more concerned in voicing his opinion that no level alarm would prevent a break-in. So my frustration with him aside, has this group confirmed that the perimeter plus is not included and therefore a reasonable addition?

  9. Rocky S

    Rocky S New Member

    Posts:
    2
    Likes Received:
    1
    Joined:
    Dec 1, 2018
    Here is the description from the Ford brochure. Don't know whether intrusion sensors are perimeter plus. That term is not mentioned as part of 802a.
    Equipment Group 802A: includes all content of 801A + 4.10 front axle with TORSEN® differential + heated and ventilated front seats with memory driver’s seat + 360-degree camera + Advanced Security Pack (includes SecuriLock® Passive Anti-Theft System and inclination/ intrusion sensors) + ambient lighting + BLIS® (Blind Spot Information System) with trailer coverage and cross-traffic alert + dual-zone electronic automatic temperature control + SYNC Connect1 + inflatable rear safety belts in outboard seating positions (SuperCrew®) + trailer brake controller + LED cargo box lighting + power-adjustable pedals with memory + Intelligent Access with push-button start + power-folding sideview mirrors with power, heated glass, memory, integrated turn signal indicators, high-intensity LED security approach lamps, LED spotlights, driver’s side auto-dimming feature, and body-color caps + bodycolor door and tailgate handles + power-tilt/-telescoping steering column with memory + heated steering wheel + Pro Trailer Backup Assist™ + Remote Start System + remote tailgate release + B&O PLAY™ Premium Audio System by HARMAN with HD Radio™ + universal garage door opener + voice-activated Navigation System
